UL2464 na UL20276 nuburyo bubiri bukoreshwa kandi bukunze kwitiranywa murwego rwinsinga zisanzwe zabanyamerika. Laboratoire zandika (UL) yateje imbere byombi, ariko ibisobanuro byabo biratandukanye kandi byashizweho mubihe bitandukanye. By'umwihariko, hari itandukaniro rigaragara ukurikije ibidukikije bikurikizwa, urwego rwa voltage, hamwe nuburyo bwo gukingira. Ihinduka ryumvikana ryibipimo bigaragarira cyane cyane mugukoresha insinga zikingiwe nuruzitiro hamwe ninsinga nyinshi - insinga zikingiwe. Kubwamahirwe, isosiyete yacu ifite ubwoko bwinsinga zombi. Noneho reka turebe itandukaniro riri hagati yubwoko bubiri bwinsinga ..
Umuvuduko na Insulation: Itandukaniro ryingenzi hagati ya 300V na 30V
UL2464 PVC Yashizwemo Multi - intangiriro ya Cableifite voltage yagereranijwe ya 300V kandi irakwiriye gukwirakwiza no hagati ya voltage yohereza no gutanga amashanyarazi. Ifite imipaka igaragara kuri diameter ya kiyobora (byibuze irashobora kuba 40AWG), kandi insulasiyo nini cyane munsi ya diameter imwe. Irashobora kwihanganira AC2000V / min kwihanganira ikizamini cya voltage. Ahanini ifata ibyiciro bibiri - urwego rwinshi - rwibanze rwikingira rwa aluminium foil na tin - zometseho umuringa, zifatanije nu gikoresho cyo gukingira PVC hamwe nigishushanyo cyo gukingira icyuma, cyoroshye, kirwanya - kwivanga, kwambara - kwihanganira amavuta -. Urubanza rusanzwe ni insinga za sisitemu yo kugenzura umutekano mu isoko. Irakeneye guhangana no gukandagira abantu, kwivanga kwa electronique no kwanduza amavuta. Icyuma gikingiraUL2464 PVC Yashizwemo Multi - intangiriro ya CableIrashobora kurwanya ibyangiritse kumubiri, kandi gukingira - gukingira ibice byerekana ibimenyetso bisobanutse. Umuvuduko wa 300V urashobora kandi kuzuza ibisabwa byo gutanga amashanyarazi kubikoresho byo gukurikirana.
Umuvuduko wa voltage yaUL20276 Multi - Umugozi uyobora umugozini 30V gusa. Yibanze ku nsinga y'imbere y'ibicuruzwa byo mu cyiciro cya 2. Nta mbogamizi zidasanzwe kuri diameter ya kiyobora. Uruhu rwiziritse ruba rworoshye, ahanini rukozwe mu nsinga z'umuringa zometseho / aluminium foil nyinshi - ingabo ikingira, kandi bamwe bakoresha reberi yo gukingira kugirango bongere imbaraga zo kunama. Ubushyuhe bwo gukora buva kuri dogere - 40 kugeza kuri +90 dogere. Irakwiriye guhuza imirongo ya robo yinganda za robo ninganda. Irashobora kuzuza ibisabwa hejuru - inshuro zunamye hamwe na - voltage yohereza ibimenyetso byerekana neza, mugihe wirinze imyanda iterwa no kugabanuka kwinshi.
Icyiciro cyo gutwika: Imikorere ya flame retardant igena imipaka yurwego rushoboka
Itandukaniro mubyiciro byo gutwika byarushijeho gusobanura imipaka ikoreshwa muburyo bubiri bwinsinga.UL2464 PVC Yashizwemo Multi - intangiriro ya Cableikeneye gutsinda VW - 1 igeragezwa ryo gutwika kandi ifite umuriro mwiza cyane. Igice kinini - cyuma gikingiwe cyuma gikozwe mumashanyarazi gikozwe mumuriro - retardant PVC, ihagarika neza umuriro gukwirakwira kandi ikwiranye nogukoresha amashanyarazi imbere mumashanyarazi atandukanye, harimo ibikoresho bya elegitoroniki n'ibikoresho byo murugo. Kurugero, insinga zihuza zihuza imbere no hanze yimiturirwa yo murugo rwagati igomba kunyura mu cyuho. Umuriro wa UL2464 - ibintu bidasubirwaho birashobora kugabanya amahirwe yumuriro, kandi gukingira ibintu byinshi birashobora kwihanganira kwivanga kwa electronique mugihe compressor ikora, byemeza ko ibimenyetso bigenzura bihamye.UL20276 Multi - Umugozi uyobora umugozi, kurundi ruhande, gusa ikeneye guhaza ibisabwa kugirango itwike itambitse, ifite urwego rwo hasi rwumuriro wa flame, kandi gukingira ibishishwa byateganijwe gusa kubidukikije imbere. Irashobora gukoreshwa gusa mubikoresho bimwe byimbere byimbere, nkibikoresho bya sensor ihuza insinga hamwe nizunguruka ryimbere ryibikoresho byikora. Kubikoresha mubidukikije bigoye birabujijwe rwose.
Igishushanyo mbonera: Guhuza neza kurinda gukomeye nuburemere
UL2464
Ifite imbaraga zo kurwanya - ubushobozi bwo kwivanga hamwe nigipimo cyo hejuru cyo gukingira urwego rukingira. Uhujije hamwe nugukingirana ibyatsi, birashobora guhangana byoroshye nimbaraga zikomeye za electromagnetic. Kurugero, mumahugurwa yuruganda, mugihe insinga yibikoresho yegereye guhinduranya imirongo, imirasire ikomeye ya electromagnetique iterwa na enterineti irashobora kubangamira ibimenyetso byoroshye. Gukingira gukomeye + gukingira ibyatsi byo guhuzaUL2464 PVC Yashizwemo Multi - intangiriro ya CableIrashobora kurwanya neza kwivanga no kwemeza imikorere isanzwe yibikoresho.
UL20276
Yibanze ku buryo bworoshye bwo kugereranya no kwerekana ibimenyetso. Muguhuza imiterere ya winch ya kabiri hamwe ningabo, irashobora kugabanya imvururu zumunyururu kandi ntizikoreshe ingamba zo gukingira.UL20276 Multi - Umugozi uyobora umugozini byiza cyane kubugufi - umurongo uhuza mubikoresho, nka wiring hagati ya sensor na Mainboard. Ntishobora kuba yujuje ibisabwa gusa ahubwo inabika umwanya wo kwishyiriraho.
Ikibazo cyo Guhitamo Ibyerekanwe: Inganda, Ubucuruzi, Sivile
Intsinga zubwokoUL2464 PVC Yashizwemo Multi - intangiriro ya Cablebirakwiriye kuri 300V ntoya kandi yoroheje ya voltage, kwivanga gukomeye hamwe nibidukikije bigoye. Bishingiye ku kirimi kinini - gisubiza inyuma icyiciro cya VW-1 hamwe no gukingira icyatsi kibisi, barashobora guhangana ningorane nyinshi nko kwambara kumubiri, irangi ryamavuta, nimirasire ya electronique.
Wiring kuri sisitemu yubwenge yo kugenzura umutekano wubucuruzi
Kabiri - gukingira ibice bikuraho amashanyarazi ya magnetiki kugirango harebwe niba ibimenyetso byerekana amashusho bitagira urubura kandi bitinda. Gukingira icyatsi ni kwambara - irwanya amavuta - gihamya. Hamwe na voltage yagereranijwe ya 300V, yujuje ibyangombwa bisabwa byo gutanga amashanyarazi no kohereza ibimenyetso kuri kamera zo kugenzura. Umuriro wa VW-1 wubahiriza ibipimo byo gukingira umuriro kubucuruzi.
Intsinga yo guhuza ibice byo murugo no hanze byurugo rwagati rwumuyaga rwinshi - sisitemu yo gutandukana
Icyuma gikingira icyuma gitandukanya ubushuhe n’isuri, kandi ingabo nyinshi - zikingira zirwanya ingufu za electromagnetiki zituruka kuri compressor, bigatuma ibimenyetso bigenzura ubushyuhe bihamye. Umuvuduko wa 300V wujuje ibyangombwa bitanga amashanyarazi haba mu nzu no hanze, kandi icyiciro cya VW-1 cya flame retardant kigabanya ibyago byo kuzunguruka insinga n’umuriro muto, bigatuma bikwiranye n’insinga zihishe mu ngo.
Automotive electronique center console wiring harness kuvugurura
Amavuta - arinda ibyatsi birinda isuri yamavuta ya moteri, kandi ubushyuhe bwayo - bukwiranye nubushyuhe bwa moteri ya dogere 60 - 80. Ibikoresho byinshi - bikingira ikuraho ibimenyetso byambukiranya ibyuma bikoresha ibikoresho bya elegitoroniki, kandi ingufu za 300V zapimwe zujuje ibyangombwa bitanga amashanyarazi kubikoresho bitandukanye byamashanyarazi kuri kanseri yo hagati.
Intsinga yaUL20276 Multi - Umugozi uyobora umugoziandika kwibanda kuri 30V hasi - voltage, hejuru - itomoye, insinga zimbere kubikoresho, hamwe no gukingira byoroheje hamwe nigishushanyo mbonera cyoroshye, byujuje ibisabwa byo kohereza ibimenyetso kubirenze - byunvikana kandi bigufi.
Umuyoboro uhuza hagati ya robo yinganda ninganda
Rubber sheath irwanya kunama n'umunaniro, bikemura ikibazo cyo kumeneka byoroshye byoroshye. Ibikoresho byoroheje - ingabo ikingira ikuraho imikorere yimodoka kandi ikanemeza neza ibimenyetso byerekana kodegisi. Umuvuduko wa 30V wapimwe neza uhuye neza na 24V imbere yumuriro wibikoresho, wirinda kugabanuka kwamashanyarazi hamwe n imyanda yumutungo.
Imbere ya sensor ihuza insinga yibikoresho byo kwipimisha
Umuyoboro mwiza wa diameter hamwe no gukingira byoroheje bizigama umwanya wimbere wigikoresho. Gukingira aluminiyumu itandukanya amashanyarazi ya elegitoroniki yumuzunguruko wa kibaho, byemeza neza amakuru yerekana sensor. Umuvuduko wa 30V wapimwe wujuje ibyiciro 2 byo hasi - urwego rwumutekano wa voltage kubikoresho byubuvuzi, birinda ibyago byo kumeneka.
Imbere ya module ihuza insinga zubwenge bwurugo
Kugoreka - couple + byinshi - ingabo ikingira ikingira ikarwanya - igishushanyo mbonera gikuraho ibimenyetso byambukiranya imipaka hagati ya module, byemeza amakuru ahamye yohereza amarembo; hamwe na 30V ya voltage yagabanijwe, irahujwe na 12V hasi - ibintu byerekana ingufu, kandi diameter ya wire yoroheje ikwiranye nuburyo bworoshye imbere mumarembo.
Incamake yo gutoranya: Hindura nkuko bikenewe kugirango wirinde ingaruka zishobora guterwa
Itandukaniro ryingenzi hagati ya UL2464 na UL20276 riri muburyo buhuye nibisabwa:UL2464ifata 300V voltage, flame retardancy, hamwe na - yuzuye yerekana insinga nkibyingenzi byayo, hamwe na - ibyingenzi bikingira hamwe nigishushanyo mbonera gikingira ibidukikije bigoye.UL20276yibanze kuri 30V voltage ntoya hamwe na - neza neza insinga zimbere. Igishushanyo cyo gukingira no gukata gishimangira cyane guhinduka no guhuza n'imihindagurikire y'ikirere. Mugihe uhitamo icyitegererezo, birakenewe kuzirikana ingufu za voltage zisabwa, igipimo cyo gutwikwa hamwe n’ibidukikije bikoreshwa, hanyuma ukerekeza ku bihe bijyanye kugira ngo wirinde ingaruka z’umutekano ziterwa n’urujijo rusanzwe, kandi icyarimwe, wirinde imyanda y’umutungo iterwa no guhitamo bikabije.
Niba wifuza kumenya byinshi kuri ubu bwoko bubiri bwimirongo, nyamuneka twandikire. Ntabwo dushaka gusubiza ibibazo byawe. (Niba ushaka kumenya ubundi bwoko bw'insinga z'insinga, nabyo ni byiza!)
